Performance
Engine
Hydraulics
Lift Geometry
Operator Comfort and Convenience
Optimized Cab
- Flip-up door for easy entry and exit, with the ability to operate the machine with the door open or closed. Unlike sliding doors on some skid steers, which can be noisier and prone to rattling due to poor sealing, the ST230V's flip-up door provides a quieter, more secure option, for a smoother and more comfortable operating experience.
- Tactile control with intuitive switches, quality joysticks, and buttons for smooth operation
- 7-inch touchscreen display for full control over machine functions such as HVAC, radio, Bluetooth, cameras, and engine data
- Operator presets and access codes on the screen for personalized settings and security
- High-quality auto-temp HVAC keeps the cab comfortable, no matter the season
Visibility and Safety
- Great side and track visibility for a clear view of the job site
- Fully enclosed cab with a metal screen on the glass for safety without sacrificing visibility
- Backup camera to help you keep track of what's behind you and avoid obstacles
- ROPS and FOPS certification for peace of mind while you work
Easy Maintenance and Durability
- The engine bay layout is simple, and filters are easily accessible for quick daily checks.
- Hydraulic components are easy to access under the cab for routine maintenance.
- The skid steer is equipped with Rexroth pumps and Bonfiglioli drive motors for long-lasting durability.
- An auto-reversing fan helps maintain optimal hydraulic cooling by clearing out the system.
- The 400mm Z-pattern tracks provide excellent traction on soft ground and uneven surfaces, with optional traction pads for extra grip in tougher conditions.
How’s it compare?
Specification | SANY ST230V | Cat 255 | John Deere 325G |
---|---|---|---|
Operating Weight | 10,318 lbs | 9,578 lbs | 9,650 lbs |
Standard Flow | 21 GPM | 23 GPM | 21 GPM |
High Flow | 31.6 GPM | 30 GPM | 32 GPM |
Gross HP | 74 hp | 74.3 hp | 74 hp |
Bucket Breakout Force | 5,733 lbs | 6,746 lbs | 8,750 lbs |
Tipping Load | 6,943 lbs | 7,140 lbs | 7,400 lbs |
Operating Capacity @ 35% | 2,430 lbs | 2,499 lbs | 2,590 lbs |
Lift Geometry | Vertical | Vertical | Vertical |
Traveling Speed | 5.4/8.5 mph | 5.7/9.1 mph | 5.2/8.2 mph |
Standard Tracks | 320mm zig-zag, 320mm block, 400mm Z-pattern | 320mm bar, 400mm block/bar | 320mm bar, 400mm bar available |
Ready for Any Job
Operating Weight | 10,318 lbs |
Standard Flow | 21 GPM |
High Flow | 31.6 GPM |
Gross HP | 74 hp |
Bucket Breakout Force | 5,733 lbs |
Tipping Load | 6,943 lbs |
Operating Capacity @ 35% | 2,430 lbs |
Lift Geometry | Vertical |
Traveling Speed | 5.4/8.5 mph |
Standard Tracks | 400mm Z-pattern |
